Note: specific production capacity is based on customer site configuration and production capacity.
Mining, metallurgy, construction, chemical, cement, refractory material, ceramics, etc.
Applicable MaterialLimestone, granite, marble, basalt, iron ore, river pebble, shale, lapis, coal, cobblestone, construction waste, etc.
The PEW series hydraulic jaw crusher is a new equipment for crushing hard or abrasive stones. The PEW series hydraulic jaw crushers are sold well in the market because of the disassembly frame without welding structure, double wedge adjusting device, elastic limit damping device and integrated motor base.
By adopting heavy design, good-quality steel plate CO2 durable.
The eccentric shaft is forged by alloy steel and subjected to finish turning, so that its bearing capacity is high. Due to the adoption of high-quality bearings and thin oil for lubrication, it has the advantages of long service life, smooth operation and convenient maintenance.
Because a deep-cavity design is adopted and the rotary speed is reasonably matched with the optimized nip angle, the maximum output is guaranteed. Because the material-discharging port is hydraulically adjusted, the operation and the maintenance are convenient and quick, and the productivity is improved.
Toggle plate is not necessary to lubricate that can protect the main machine in case of overload and ensure the complete machine.
Input dynamic by motor, the pulley drives eccentric shaft to make the movable jaw move upwards and downwards with SPC belt. When the movable jaw moves forth toward the fixed jaw, materials in the crushing cavity will be squashed or chopped. And then the movable jaw travels back, the chopped or squashed materials which met the requirements will be discharged from the outlet. Since the motor keeps working, the crusher will crush and discharge periodically to achieve mass production.
| Model | PEW860 | PEW1100 | PEW200×1300 | PEW250×1000 | PEW250×1200 | PEW400×600 | |
| Feeding Opening(mm) | 860×1100 | 1100×1200 | 200×1300 | 250×1000 | 250×1200 | 400×600 | |
| Feeding Size(mm) | ≤720 | ≤930 | ≤180 | ≤220 | ≤220 | ≤350 | |
| Discharge Setting(mm) | 100-225 | 150-275 | 10-30 | 20-40 | 20-40 | 35-85 | |
| Eccentric Shaft Rotation Speed(rpm) | 240 | 210 | 320 | 330 | 330 | 250 | |
| Capacity(t/h) | 200-500 | 300-650 | 12-35 | 15-50 | 20-50 | 15-70 | |
| Electric Motor | Power(kW) | 132～160 | 185～200 | 30～37 | 30～37 | 37～45 | 37～45 |
| Rotation Speed(rpm) | 985 | 740 | 980 | 980 | 980 | 980 | |
| Overall Dimension(L×W×H)(mm) | 3300×2320×3120 | 4140×2660×3560 | 1320×2150×1175 | 1400×1850×1310 | 1400×2050×1310 | 1920×1460×1840 | |
| Weight(kg) | 32000 | 59200 | 7500 | 6800 | 7800 | 8000 | |
